Le Infezioni in Medicina, n. 2, 277-284, 2022

doi: 10.53854/liim-3002-14

CASE REPORT

Thoracic aorta graft infection by avibactam-resistant KPC-producing K. pneumoniae treated with meropenem/vaborbactam: a case report and literature review

Alessandra Belati1, Roberta Novara1, Davide Fiore Bavaro1, Andrea Procopio1, Cecilia Fico1, Lucia Diella1, Federica Romanelli2, Stefania Stolfa2, Adriana Mosca2, Francesco Di Gennaro1, Annalisa Saracino1

1Clinic of Infectious Diseases, University of Bari, University Hospital Policlinico, Bari, Italy;

2Microbiology and Virology Unit, University of Bari, University Hospital Policlinico, Bari, Italy

Article received 13 February 2022, accepted 21 April 2022

Corresponding author

Davide Fiore Bavaro

E-mail: davidebavaro@gmail.it

SummaRY

Meropenem/vaborbactam (M/V) is a new carbapenem-carbapenemase inhibitor combination drug active against extensively drug resistant Gram-negative pathogens. Studies about its efficacy and place in therapy are limited in “real-life” and no data are available for deep site infections, like vascular graft infections.

We present a case of a patient successfully treated with M/V for a thoracic aorta graft infection, placed for a traumatic penetrating aortic ulcer, due to an extensively KPC-producing Klebsiella pneumoniae resistant to ceftazidime/avibactam.

Furthermore, we conducted a systematic literature review concerning vascular graft infections caused by carbapenem-resistant Klebsiella pneumoniae and the papers published until now about the use of M/V for the treatment of ceftazidime/avibactam-resistant K. pneumoniae.

Meropenem/vaborbactam is a promising antibiotic for difficult-to-treat Gram-negative bacteria with limited therapeutic options. Only few reports have been published and more studies are needed to assess which is the best place in therapy of M/V.

Keywords: meropenem/vaborbactam, KPC-Klebsiella pneumoniae, thoracic aorta graft infection, antimicrobial resistance, hospital acquired infections.

INTRODUCTION

The progressive increase of antimicrobial resistance in recent years, particularly diffuse among Gram-negative bacteria (GNB), represents a major concern for public health in terms of morbidity and mortality, leading to a critical need for new antimicrobials to face this threat [1].

In this scenario, new molecules have been recently commercialized: cefiderocol, imipenem/cilastatin/relebactam and meropenem/vaborbactam represent the newest therapeutic options for “difficult-to-treat” GNB infections but data are still limited to clinical trials or small case series [2, 3].

Of these, meropenem/vaborbactam (M/V) is the first carbapenem/β-lactamase inhibitor combination, which is used to treat multidrug-resistant (MDR) GNB infections, specifically KPC-producing carbapenem-resistant Enterobacteriaceae (KPC-CRE). It combines an old carbapenem (meropenem) with vaborbactam, a non-β-lactam cyclic boronic acid pharmacophore, highly efficient at hydrolyzing serine β-lactamases including class A (KPC, CTX-M, SHV, and TEM) and class C (P99, MIR, and FOX) β -lactamases [4, 5].

Interestingly, 90% of carbapenem-resistant GNB tested in a recent in vitro study exhibited a minimum inhibitory concentration (MIC) less than or equal to the susceptible Food and Drug Administration (FDA)-approved breakpoint for Enterobacteriaceae (≤4/8 µg/mL), suggesting an important place in therapy of M/V in this setting [6].

Currently, the European Medicines Agency and the FDA approved M/V with limited indications, on the basis of the published trials TANGO I and TANGO II: complicated urinary tract infections (cUTI), complicated intra-abdominal infections (cIAI); hospital-acquired pneumonia (HAP), including ventilator associated pneumonia (VAP), and for the treatment of patients with bacteremia that occurs in association with, or is suspected to be associated with, any of the infections listed above. M/V is also indicated for the treatment of infections due to aerobic GNB in adults with limited treatment options [7-9].

However, important knowledge gaps persist in terms of “real-life” data, including treatment of very complex clinical pictures, such as device/biofilm-related infections by KPC-CRE. For instance, vascular graft/endograft infections (VGEIs) lie within the most challenging and threatening complication of graft implantation. Although uncommon (occurring in 0.2-0.7% of patients), they are associated with a very intricate management, costs, morbidity, and mortality.

In this paper, we report the first case of a thoracic aorta graft infection, due to a KPC-producing Klebsiella pneumoniae (KPC-Kp), extensively resistant to antimicrobials, including ceftazidime/avibactam (CAZ/AVI), but effectively treated with M/V.

CASE REPORT

Due to multiple vertebral fractures following an accidental 2-meters-drop, in April 2021 a 71-year-old male was admitted to the Neurosurgery ward of our hospital, where he underwent a surgical vertebral stabilization of D9-D12. Nevertheless, the trauma resulted in paraplegia, sternal fracture, costal fractures, multiple contusive hemorrhagic focuses, and a post-traumatic penetrating aortic ulcer (PAU). After the surgery, he was hospitalized in the intensive care unit (ICU) where he remained one month, until the discharge to a rehabilitation facility in May 2021. The rectal swab performed at the time of discharge showed a colonization by KPC-Kp, while the culture of tracheal aspirate was positive for carbapenem-resistant Acinetobacter baumannii. Unfortunately, we did not have access to the medical records of the previous hospitalizations and administered antibiotic therapies.

He was newly admitted to the vascular surgery unit on May 27th, 2021, to undergo a thoracic aorta graft positioning for PAU with left subclavian artery exclusion and carotid-subclavian bypass. The surgical procedure was well tolerated, and he was discharged back to the rehabilitation facility after few days. Unfortunately, due to the prolonged orotracheal intubation, the patient developed a swallowing disfunction related to the incoordination of the deglutition muscles; therefore, on June 10th a central venous catheter (CVC) was positioned to allow rehydration and parenteral nutrition until full recovery of dysphagia. At the end of June, the patient had fever with chills and hypotension, so he started an empiric therapy with meropenem (2 g, three times daily) and tigecycline (50 mg, two times daily) in the rehabilitation facility, but, for the persistence of symptomatology, on June 28th he was conducted to our Emergency Department. Blood cultures and the culture of the tip of removed CVC resulted all positive for KPC-Kp with a high MIC to CAZ/AVI=4 mg/L (Vitek2 automated system). He also performed a CT-scan with no evidence of sources of infection; also, the thoracic aorta graft appeared free from signs of endoleak or infection (Figure 1a).

On July 6th he was admitted to our ward. The CVC was immediately removed, and the patient became quickly apyretic showing also a significantly reduction of inflammation markers. Moreover, three negative follow-up blood cultures were obtained after CVC removal; accordingly, the therapy with meropenem and tigecycline was stopped. Hence, the patient was transferred to the rehabilitation unit of our hospital. Unfortunately, the patient presented a new episode of fever, chills and hypotension: new blood cultures were performed which resulted positive for KPC-Kp resistant to CAZ/AVI (MIC >8 mg/L with Vitek2 automated system). Microdilution test (SensititreTM, Thermo Fisher Scientific) for colistin and E-test (ETEST® Meropenem/Vaborbactam Liofilchem®) for M/V were performed, showing MIC of 0.5 ug/mL and 3 ug/mL, respectively. According to the clinical breakpoints established by the European Committee on Testing (EUCAST), the isolate was considered susceptible to both M/V and colistin (Table 1). It was not possible to evaluate the mechanism of CAZ/AVI resistance as no sequencing/genetic tests are available in our hospital.

The patient was then evaluated by the Infectious Diseases (IDs) consultant: a combination therapy with M/V 4 gr tid in 3-h infusion associated with colistin 9 MIU as first dose followed by 4.5 MIU bid in 1-h infusion was started, in accordance with the patient body mass index (26,4 kg/m2, weight 78 kg, height 172 cm). Follow up blood cultures were prescribed, starting after 48 hours of effective antimicrobial therapy.

At the 72h-IDs follow-up evaluation, the inflammatory markers were persistently elevated along with fever. Therefore, the patient was transferred back to our ID Unit, suspecting a deep-site infection. On the sixth day of therapy, given the acquisition of the 2 of 3 positive and 1 of 3 negative follow-up blood cultures, and the persistence of high inflammatory markers associated with irregular episodes of low-grade fever, diagnostic tests to seek sources of infection were requested, and colistin was replaced by tigecycline 100 mg bid in 1-h infusion in order to ensure a higher activity on a possible deep-site of infection along with a better tolerability.

Consequently, the patient underwent a trans-thoracic echocardiography (negative for endocarditic vegetations) and an 18-FDG PET/CT scan, evidencing an aortic prosthesis infection (SUV max= 17.6) and a by-pass infection (SUV max=4.3) with no other areas of hyperaccumulation of the radiopharmaceutical (Figure 1b). Based on current guidelines on VGEIs, this case was considered compatible with a KPC-Kp-caused thoracic aorta graft infection [10].

Figure 1 – Imaging. 1a. Computed tomography. Note: no evidence of sources of infection. The thoracic aorta graft appeared free from signs of endoleak or infection. 1b. 18-FDG-PET/CT. Note: the red arrows show the areas of radiopharmaceutical hyperaccumulation at the level of the aortic prosthesis. Graft infection, SUV max = 17.6; By-pass infection, SUVmax = 4.3.

Additionally, a new vascular surgery evaluation was performed: a diagnosis of early VGEI was established, but the high risk of mortality contraindicated the procedure of explantation/reimplantation of the graft.

After 3 weeks of combination therapy, thanks to the achieved clinical stability of the patient, and because of a suspected toxicity (hyperbilirubinemia), tigecycline was stopped and M/V was continued until the discharge, for a total of 6 weeks of therapy. Persistent negative blood cultures were obtained during hospitalization, after the start of targeted therapy. No adverse event to M/V was reported.

Consequently, the patient was discharged, in stabilized clinical conditions, with no antibiotic therapy.

According to our internal clinical practice, in absence of oral suppressive chronic antibiotic therapy strategies, the patient was addressed to a tight follow-up, in order to immediately start a new inpatient antibiotic therapy in case of infection recrudescence.

Anyway, after 2 months from discharge, no relapse of the infection was recorded. The patient unfortunately died before completing further follow-up due to a breakthrough pneumonia complicated by acute respiratory distress syndrome and acute heart failure.

Timeline of events is summarized in Figure 2.

Figure 2 - Timeline of events. Note: PAU = Penetrating aortic ulcer; MEM = Meropenem; TGC = Tigecycline; CVC = Central Venous Catheter; ID = Infectious Diseases; Rehab = Rehabilitation; M/V = Meropenem/Vaborbactam; COL = Colistin.

LITERATURE REVIEW

We conducted a literature search on PubMed, Scopus, Google Scholar, EMBASE and Cochrane Library starting from January 1996, the year when the first KPC-Kp has been identified, to November 2021, in order to identify articles concerning VGEIs caused by KPC-Kp [11]. For this, we included the words “KPC” “carbapenem resistant” matched with “endovascular infections” or “graft infections”. Reviews and meta-analyses have been excluded. A total of 514 papers have been screened and finally only 2 papers have been included.

Carbapenem-resistant Enterobacterales are rarely reported as causative agents of VGEIs. Usually, the primary causative agents of these infections are Gram positive bacteria (mostly Staphylococcus aureus, Enterococci and coagulase-negative Staphylococci) accounting up to 58%, while GNB are reported in 34% of cases [12]. In this scenario, the optimal treatment strategies in VGEIs are still unknown and the management should be decided by a multidisciplinary team, including IDs specialists, vascular surgeons, radiologists, microbiologists, anaesthetists to guide the patient diagnostic and therapeutic pathway.

To date, the only two studies that report of VGEIs due to KPC-Kp, describe respectively a case series (including 3 patients) and a case report [13, 14].

In the study of Yun-Shi Cai et al., three patients received organ transplantation (liver and kidneys) from the same donor with CR-Kp BSI at the time of death [13]. The recipients experienced a graft arterial rupture due to sepsis from CR-Kp. The liver recipient developed hepatic artery thrombosis and cIAI (hepatic and peritoneal abscesses) and was treated with multiple percutaneous peritoneal drainage and, according to antibiogram, with sulfamethoxazole and polymixin B for 7 months, with normalization of inflammatory markers and reduction in size of the liver and peritoneal abscesses, but the culture of drainage fluid persistently positive for CR-Kp. Finally, the kidney recipients experienced rupture of renal artery anastomosis and underwent graft nephrectomy and haemodialysis, pending for a new transplantation.

Montelione et al. described a case of a patient with a late VGEI caused by CR-Kp, treated with endograft removal and in situ aortic reconstruction and a double carbapenem-regimen for 4 weeks, with no recurrence of infection after three years [14].

In addition, another issue of our case was the resistance to CAZ/AVI, which represents, nowadays, the cornerstone of the antibiotic regimen against KPC-Kp [15].

Therefore, in addition to the previous literature review already described, we carried out another literature search on the same databases from 2017, the year of approval by the Food and Drug Administration of M/V, until November 2021, directed to investigate the post-marketing real-life experiences of the use of M/V for the treatment of CAZ/AVI-resistant K. pneumoniae. We included the words “vaborbactam” “meropenem/vaborbactam” matched with “ceftazidime/avibactam resistant” or “avibactam resistant”. Reviews and meta-analyses have been excluded. A total of 532 articles have been screened and finally only 6 papers have been included, particularly 3 case reports and 3 case series, and are summarized in Table 2 [16-21].

Ackley et al., in a multicentre retrospective cohort study of adults with CRE infections, compared the use of CAZ/AVI vs M/V in a 3-years period, including 131 patients (CAZ/AVI, n=105; M/V, n=26) and neither significant difference in clinical success was observed between groups (62% versus 69%; P=0.49), nor in recurrence rate, but the development of resistance was more common with CAZ/AVI monotherapy [16].

Alosaimy et al. recently published a multicenter, retrospective cohort study including 126 patients treated with M/V for a variety of GNB infections, primarily including KPC-CRE. Thirty-day mortality and recurrences occurred in 18.3% and 11.9%, respectively, and adverse events occurred in 4 patients [17].

Shields et al. described the use of M/V in 20 patients with KPC-CRE at a large academic facility. Success was achieved in 65%, and 30-days survival rate was 90%. Microbiological failure occurred in 35% of patients. Only one case of a patient developing an intra-abdominal infection due to a M/V resistant KPC-3 isolate after 12 days of treatment was reported [18].

DISCUSSION

In our case, since the rarity of VGEIs caused by carbapenem-resistant Klebsiella pneumoniae, the suspicion of VGEI was based on the persistence of low-grade fever, elevated inflammatory markers and, particularly, positive follow up blood cultures for KPC-Kp, despite effective antibiotic therapy. Indeed, accordingly to our internal guidelines, follow up blood cultures are usually prescribed in all cases of BSIs, independently of the causative pathogen, and are used to assess the effectiveness of the antibiotic therapy, as well as the potential presence of deep-site infections.

The multidisciplinary team in our case posed the diagnosis of early VGEI (<4 months), that is usually caused by a discontinuation of sterility during implantation (a possible explanation of our case) or a previous thrombus infection; conversely, late VGEIs (>4 months) are mostly caused by hematogenous dissemination [10].

Because of the impossible surgical source control, we prescribed a prolonged course of antimicrobial therapy based on M/V, selected on the basis of the high tolerability and noticeable efficacy on biofilm and deep-site infections [19]. Interestingly, this approach could be feasible in subjects without surgical options, as suggested by multiple studies conducted in this setting, where one-year mortality was similar in both conservatively and surgically treated patients [20-22].

Resistance to CAZ/AVI in the case of KPC-Kp would require both a phenotypic and a genotypic approach in order to better understand the mechanism. These tests should be available in all tertiary care facilities facing up complicated infections, to allow a tailored approach to therapy, considering the pathogen susceptibility. In our case, there are no genotypic or genomic sequencing tests, but, from in vitro studies, it would seem that resistance mutations to CAZ/AVI evidenced until now apparently does not affect sensitivity to M/V, which therefore represents a valid therapeutic alternative option, as demonstrated by phenotypic testing, in which Klebsiella maintained sensitivity to M/V (Table 1) [23].

Our case represents a unique challenge, due to the rarity of VGEIs, especially due to a CAZ/AVI-resistant KPC-Kp. In this case, the use of M/V was crucial in obtaining the suppression of acute infection, followed by a careful “watch and wait” strategy in a patient with deep-site infection not eligible for surgery and no available treatments options for long-term suppressive therapy at home.

In this scenario, the correct place in therapy of new drugs is pivotal: in our experience, M/V could represent a first-line therapy particularly for deep-site KPC-Kp disease and for avibactam-resistant KPC-Kp infections.

Funding

None

Conflict of interests

No author has any conflict of interest to declare.

Ethical approval

The research did not require a formal approval from the ethics committee according to the Italian law since it was performed as an observational retrospective study in the context of normal clinical routines (art.1, leg. decree 211/2003). However, the study was conducted in accordance with the Declaration of Helsinki and national and institutional standards. The patient provided informed consent for the use of his data for research purposes. In any case, data were previously anonymized, according to the requirements set by Italian Data protection Code (leg. Decree 196/2003).

REFERENCES

[1] Bassetti M, Poulakou G, Ruppe E, Bouza E, Van Hal SJ, Brink A. Antimicrobial resistance in the next 30 years, humankind, bugs and drugs: a visionary approach. Intensive Care Med. 2017; 43 (10), 1464-75. https://doi.org/10.1007/s00134-017-4878-x

[2] Pontefract BA, Ho H T, Crain A, Kharel MK, Nybo SE. Drugs for Gram-negative bugs from 2010-2019: a decade in review. Open Forum Infect Dis. 2020; 7 (7), ofaa276. https://doi.org/10.1093/ofid/ofaa276

[3] Bavaro DF, Belati A, Diella L, et al. Cefiderocol-Based Combination Therapy for “Difficult-to-Treat” Gram-negative severe infections: real-life case series and future perspectives. Antibiotics (Basel, Switzerland). 2021; 10 (6), 652. https://doi.org/10.3390/antibiotics10060652.

[4] Castanheira M, Rhomberg PR, Flamm RK, Jones RN. Effect of the β-lactamase inhibitor vaborbactam combined with meropenem against serine carbapenemase-producing Enterobacteriaceae. Antimicrob Agents Chemother. 2016; 60 (9), 5454-8. https://doi.org/10.1128/AAC.00711-16.

[5] Shoulders BR, Casapao AM, Venugopalan V. An update on existing and emerging data for meropenem-vaborbactam. Clin Ther. 2020; 42 (4), 692-702. https://doi.org/10.1016/j.clinthera.2020.01.023.

[6] Jorgensen S, Rybak MJ. Meropenem and vaborbactam: stepping up the battle against carbapenem-resistant enterobacteriaceae. Pharmacother. 2018; 38 (4), 444-61. https://doi.org/10.1002/phar.2092.

[7] Kaye KS, Bhowmick T, Metallidis S, et al. Effect of meropenem-vaborbactam vs piperacillin-tazobactam on clinical cure or improvement and microbial eradication in complicated urinary tract infection: The TANGO I randomized clinical trial. JAMA, 2018; 319 (8), 788-99. https://doi.org/10.1001/jama.2018.0438.

[8] Wunderink RG, Giamarellos-Bourboulis EJ, Rahav G. Effect and safety of meropenem-vaborbactam versus best-available therapy in patients with carbapenem-resistant enterobacteriaceae infections: the TANGO II randomized clinical trial. Infect Did Ther. 2018; 7 (4), 439-55. https://doi.org/10.1007/s40121-018-0214-1.

[9] Assement report on Meropenem-Vaborbactam. 20 September 2018 EMA/CHMP/700663/2018 Committee for Medicinal Products for Human Use (CHMP)] [Vabomere® (meropenem/vaborbactam) [prescribing information]. Parsippany, NJ: The Medicines Company; (2017).

[10] Chakfé N, Diener H, Lejay A, et al. Editor’s Choice - European Society for Vascular Surgery (ESVS) 2020 clinical practice guidelines on the management of vascular graft and endograft infections. Eur J Vasc Endovasc Surg. 2020; 59 (3), 339-84. https://doi.org/10.1016/j.ejvs.2019.10.016.

[11] Yigit H, Queenan AM, Anderson GJ, et al. Novel carbapenem-hydrolyzing beta-lactamase, KPC-1, from a carbapenem-resistant strain of Klebsiella pneumoniae. Antimicrob Agents Chemother. 2001; 45 (4), 1151-61. https://doi.org/10.1128/AAC.45.4.1151-1161.2001

[12] Legout L, D’Elia PV, Sarraz-Bournet B, et al. Diagnosis and management of prosthetic vascular graft infections. Med Mal Infect. 2012; 42 (3), 102-9. https://doi.org/10.1016/j.medmal.2012.01.003

[13] Cai YS, Xiao H, Zhang S, et al. Carbapenem-resistant Klebsiella pneumoniae infection causing rupture of graft artery in solid organ recipients : Case report and review of literature. Medicine. 2019; 98 (45), e17878. https://doi.org/10.1097/MD.0000000000017878

[14] Montelione N, Menna D, Sirignano P, Capoccia L, Mansour W, Speziale F. Open conversion after aortic endograft infection caused by colistin-resistant, carbapenemase-producing Klebsiella pneumoniae. Texas Heart Inst J. 2016; 43 (5), 453-7. https://doi.org/10.14503/THIJ-15-5265.

[15] Wang Y, Wang J, Wang R, Cai Y. Resistance to ceftazidime-avibactam and underlying mechanisms. J Glob Antimicrob Resist 2020; 22, 18-27. https://doi.org/10.1016/j.jgar.2019.12.009

[16] Ackley R, Roshdy D, Meredith J, et al. Meropenem-vaborbactam versus ceftazidime-avibactam for treatment of carbapenem resistant Enterobacteriaceae infections. Antimicrob Agents Chemother. 2020; 64 (5), e02313-19. https://doi.org/10.1128/AAC.02313-19.

[17] Alosaimy S, Lagnf AM, Morrisette T, et al. Real-world, multicenter experience with ]meropenem-vaborbactam for Gram-negative bacterial infections including carbapenem-resistant Enterobacterales and Pseudomonas aeruginosa. Open Forum Infect Dis. 2021; 8 (8), ofab371. https://doi.org/10.1093/ofid/ofab371

[18] Shields RK, McCreary EK, Marini RV, et al. Early experience with meropenem-vaborbactam for treatment of carbapenem-resistant enterobacteriaceae infections. Clin Infect Dis. 2020; 71 (3), 667-71. https://doi.org/10.1093/cid/ciz1131.

[19] Sabet, M., Tarazi, Z., Nolan, T., et al. Activity of meropenem-vaborbactam in mouse models of infection due to kpc-producing carbapenem-resistant enterobacteriaceae. Antimicrob Agents Chemother. 2017; 62 (1), e01446-17. https://doi.org/10.1128/AAC.01446-17

[20] Lyons OT, Patel AS, Saha P, Clough RE, Price N, Taylor PR. A 14-year experience with aortic endograft infection: management and results. Eur J Vasc Endovac Surg. 2013; 46 (3), 306-13. https://doi.org/10.1016/j.ejvs.2013.04.021.

[21] Luehr M, Etz CD, Nozdrzykowski M, et al. Emergency open surgery for aorto-oesophageal and aorto-bronchial fistulae after thoracic endovascular aortic repair: a single-centre experience†. Eur J Cardiotharac Surg. 2015; 47 (2), 374-383. https://doi.org/10.1093/ejcts/ezu147.

[22] Kahlberg A, Melissano G, Tshomba Y, Leopardi M, Chiesa R. Strategies to treat thoracic aortitis and infected aortic grafts. J Cardiovasc Surg. 2015; 56 (2), 269-80.

[23] Wang Y, Wang J, Wang R, Cai Y. Resistance to ceftazidime-avibactam and underlying mechanisms. J Glob Antimicrob Resist. 2020; 22, 18-27. https://doi.org/10.1016/j.jgar.2019.12.009.
